316 Stainless Torx Eccentric Screws ±0.3-1.0mm Offset Electropolished

Name: 316 Stainless Torx Eccentric Screws 0310mm Offset Electropolished
Brand: guanbiao
Price: 1 USD

Buy cheap 316 Stainless Torx Eccentric Screws ±0.3-1.0mm Offset Electropolished product

Brand Name : guanbiao

Model Number : M3x10mm to M6x50mm

Certification : ISO9001

Place of Origin : China

MOQ : 50000

Price : Negotiable

Payment Terms : T/T

Supply Ability : 5000000

Delivery Time : 15-20 work days

Packaging Details : Plastic bag + carton + pallet

Usage : Adjusting eccentricity

Package Quantity : 50000

Exterior : smooth

Color : Natural color of stainless steel, Customizable

Package : 1000PCS

Screw Drive Diameter : Customizable

Finsh : Passivation + Electropolishing (Ra<0.2µm)

Eccentricity : ±0.3mm, ±0.5mm, ±0.8mm, ±1.0mm

Contact Now

Precision Torx Eccentric Screws - 316 Stainless - ±0.3-1.0mm Offset - Medical/Marine - Electropolished

Micro-adjustment A4-80 Torx eccentric screws. ±0.3-1.0mm offset for precision alignment. 316 stainless steel. Passivated/electropolished. For medical devices, optical equipment & marine. T10-T30 sizes.

Achieve **micron-level alignment** in sensitive applications with **A4 Stainless Torx Eccentric Screws**. The **precision-ground offset shank (±0.3-1.0mm)** corrects minor hole misalignments in instruments, while **316 stainless steel (A4-80)** resects salt water, chemicals, and sterilization. **Electropolished finish** ensures hygienic surfaces for medical/lab use. .

316 Stainless Torx Eccentric Screws ±0.3-1.0mm Offset Electropolished

TECHNICAL SPECIFICATIONS
Drive Type	Torx (Standard)
Eccentric Offset (e)	±0.3mm, ±0.5mm, ±0.8mm, ±1.0mm
Torx Size	T10 (M3), T15 (M4), T20 (M5), T25 (M6)
Sizes	M3x10mm to M6x50mm
Tensile Strength	800 MPa
Material	A4-80 Stainless Steel (316L)
Surface Treatment	Passivation + Electropolishing (Ra<0.2µm)
Max Plate Thickness	8mm (per side)
Customization	Custom offsets, electropolishing, low-profile heads

316 Stainless Torx Eccentric Screws ±0.3-1.0mm Offset Electropolished

Primary Uses & Applications:

- Medical device assembly
- Optical equipment calibration
- Laboratory instrument mounts
- Marine sensor housings
- Semiconductor tooling

316 Stainless Torx Eccentric Screws ±0.3-1.0mm Offset Electropolished

How to Use:

1. **Calculate** hole deviation direction.
2. **Rotate** screw to match offset angle.
3. **Hand-tighten** initially with **Torx driver** (e.g., T20 for M5).
4. **Final torque**: 2-4 Nm (M5) to avoid deformation.
